MA050 MA Hand Chain Hoist 10' lift 5 Ton Capacity


SKU: MA050 All Material Handling

AMH 5 Ton MA Series Hand Chain Hoists

All Material Handling’s MA Series hand chain hoists offer quality and value in capacities of ½ to 30 Tons, with standard lifts of 10, 15 or 20 feet. The MA050 is the 5-ton hoist with a 10 foot lift. The MA series manual chain hoists are designed to resist corrosion and feature bolted hook blocks that allow for easy dis-assembly for inspection and replacement.

MA Manual Chain Hoist Features

Model # MA050 features 5-Ton capacity and 10 feet of lift. All Model MA’s are assembled and tested in the USA. The maintenance manual is available in English, Spanish and French. Additional key features of the MA series manual chain hoists include:

  • Premium Grade 80 Zinc Plated Alloy Load Chain

  • Lightweight & Durable all steel construction with powder-coated finish and plated frame components to resist corrosion

  • Bolted Hook Blocks allow complete hook inspections

  • Self-adjusting Double Pawl Brake - This disc type mechanical load brake ensures positive load control

  • Rounded Hand Chain Entrance - Hand chain opening is formed with a radius for smooth operation

  • Optional Overload Protection is a one directional clutch that will only slip in the lift direction

  • Meets industry standards, such as ASM B30.21, OSHA, NASA-STD-87.19.19, ATEX rated EX II 3 GD C 11B 54 degrees CX (for limited use in hazardous locations)

AMH Manual Chain Hoists for Sale

Shupper-Brickle Equipment is an authorized distributor for All Material Handling. Contact us for hoist sales and service or ask us if you need these special features:

  • Self-Locking hook option
  • Custom hand or load chain lengths
  • Optional Overload Protection Device

To place your MA050 5-ton manual chain hoist order contact us through this website or call 800-642-7263.

Don’t see what you need? With over 50 years in the business, we know hoists! Contact us for hoists, overhead cranes or service. We provide hoist repairs at your location in the Mid-Atlantic States or in our hoist repair workshop in Clarksburg, NJ.
