MA020 MA Hand Chain Hoist 10' lift 2 Ton Capacity


SKU: MA020 All Material Handling

All Material Handling 2-Ton MA Manual Chain Hoist

All Material Handling’s MA Series hand chain hoists offer quality and value in capacities of ½ to 30 Tons, with standard lifts of 10, 15 or 20 feet. This is the 2-ton capacity chain hoist with a 10-foot lift. An additional pinion shaft bearing and close tolerances allow this hand chain hoist to offer increased efficiency. It’s lightweight yet durable all steel construction features a plated frame and guide components and a rounded hand chain entrance for zinc plated chains.

Key Features of the AMH MA Series Hoists

Model # MA020 features 2-Ton capacity and 10 feet of lift. All Model MA’s are assembled and tested in the USA. The maintenance manual is available in English, Spanish and French. Other features of the MA series hand chain hoists include:

  • Premium Grade 80 Zinc Plated Alloy Load Chain

  • Lightweight & Durable all steel construction with powder-coated finish and plated frame components to resist corrosion

  • Bolted Hook Blocks allow complete hook inspections

  • Self-adjusting Double Pawl Brake - This disc type mechanical load brake ensures positive load control

  • Rounded Hand Chain Entrance - Hand chain opening is formed with a radius for smooth operation

  • Optional Overload Protection is a one directional clutch that will only slip in the lift direction

  • Meets industry standards, such as ASM B30.21, OSHA, NASA-STD-87.19.19, ATEX rated EX II 3 GD C 11B 54 degrees CX (for limited use in hazardous locations)

2 Ton Manual Chain Hoists for Sale

As an authorized distributor for AMH, Shupper-Brickle Equipment offers hoist sales, OEM replacement parts and comprehensive services. Ask us if you need these special features for the MA020:

  • Self-Locking hook option
  • Custom hand or load chain lengths
  • Optional Overload Protection Device

To place your order for All Material Handling’s 2-ton MA020 manual chain hoist, contact us through this website or call our sales engineers at 800-642-7263.

Don’t see what you need? With over 50 years in the industry, we know hoists! Contact us for hoists, overhead cranes. training, inspections or service. We provide hoist repairs at your location in the Mid-Atlantic States or in our hoist repair workshop in Clarksburg, NJ.
