Harrington ED-DSA Electric Chain Hoists
Harrington's ED series of electric chain hoists offer a powerful, versatile tool with a variety of options including low headroom designs and a variety of lift speeds. The convenient single-phase power makes their ED hoists ideal for both commercial and industrial applications.
The ED-DSA electric chain hoists have easy-to-use controls that allow the hoists to handle small and awkward loads with precision. They are available in hoisting capacities of 125 lbs to 1050 lbs, with a standard 10’ lift, and voltage of 120-1-160. A plastic chain container is standard. This is the ED-350-DSA, which features a 350 lb capacity, 10 ft of lift, and dual adjustable lifting speeds with infinity pendant.
Features of Harrington's ED-DSA Electric Chain Hoists
Harrington’s ED-DSA series of electric chain hoists are quick-lifting, single-phase speed demons. The compact DC motor keeps production moving by reducing weight, generating less heat, and maintaining duty cycles.
Model #ED350DSA features 350 lb capacity, 10 ft of lift, and dual adjustable lifting speeds with infinity pendant (high speed: 66 FPM, low speed: 13 FPM). Other key features of this hoisting equipment includes:
- Double Braking System provides extra safety with a Weston-style mechanical load brake and a regenerative brake. Standard upper limit switch prevents overlifting.
- Compact Design for easy installation and storage, lightweight & low headroom.
- Heavy Duty Motor – DC motor with rectifier for AC current reduces weight, generates less heat and maintains duty cycles.
- Suspension Options include standard hook mount or an optional trolley mount.
- Benefits of the Dual Speed Infinity (DSA) Models include customizable Speed Adjustment and the Heavy Duty Metal Hinged Cover protects the pendant knobs from damage.
Hoisting Equipment for Sale
Shop Shupper-Brickle Equipment’s wide selection of hoisting equipment. As an authorized distributor for Harrington Hoists, we sell and service all Harrington hoist models including the 350 LB ED-DSA dual speed chain hoist. With years of experience and a full-service engineering department, we can assist you with special features and upgrades such as:
- Trolley Mounting
- Additional lift or pendant length
- Power supply length over 16’ standard
If you are ready to place your order for a Harrington ED350DSA single phase chain hoist, contact us through this website or call 800-642-7263.
Don’t see what you need? With over 50 years in the business, we know hoists! Contact us for hoists, overhead cranes or related services, including OSHA inspections and turn-key installations. We provide hoist repairs at your facility in the Mid-Atlantic States or in our hoist repair workshop in Clarksburg, NJ.
Harrington ED Electric Chain Hoist Downloads
For additional information on Harrington’s ED series electric chain hoists, check out these helpful downloads.
Model ED Catalog with Specs and Dimensions
Model ED Manual with Parts Breakout
Model ED Full Owners Manual
