CB020-10-08 Badger CB Series Hand Chain Hoist, 2 Ton Capacity, 10' Lift


SKU: CB020-10-08Z All Material Handling

2 Ton AMH Badger CB Manual Chain Hoist

All Material Handling's model Badger CB hand chain hoist is lightweight and durable, with low headroom and sharp pricing. The CB020-10-08 is a 2-ton hoist with a 10’ lift. Other Badger CB manual chain hoists are available in capacities of 1/2 Ton to 10 Tons and in standard lifts of 10, 20 or 30 ft.

Badger CB Series Features

Model #CB020-10-08 features 2 Ton capacity and 10 ft of lift. All Badger CB series models feature grade 80 zinc plated alloy chain. Every unit is proof tested at a minimum of 1.25 the WLL and shipped with a load test certificate as well as an operation manual in English, Spanish and French. Additional key features these manual chain hoists from AMH include:

  • Designed for easy disassembly and fast maintenance

  • Operation from either side (or even above), since the hand chain opening is formed with a radius

  • Superior internal parts are heat-treated for strength & reliability, all gearing is fully enclosed to protect from contamination, the lift wheel is machined for smooth operation

  • Weston-style mechanical load brake with double pawls and asbestos-free brake discs that never require adjustment

  • Drop forged Alloy hooks are designed to stretch before chain failure when overloaded, the top hook articulates to aid in rigging

  • Optional Overload Protection at approximately 175% WLL

  • Meets industry standards including ASME B30.21, OSHA, NASA-STD-8719.9

AMH Manual Chain Hoists for Sale

As an authorized distributor for All Material Handing, we sell and service all Badger CB manual chain hoists, including the 2-ton CB0201-10-08. Contact us for AMH hoist sales and service or if you need:

  • An unchained unit or a customized lift
  • Optional overload protection device

To place your order for the 2 ton CB0201-10-08 manual chain hoist, contact us through this website or call 800-642-7263.

Don't see what you need? With over 50 years in the business, we know hoists! Contact us for hoists, overhead cranes or comprehensive services, such as OSHA inspections and turn-key installation. We provide equipment diagnosis and repair at your facility in the Mid-Atlantic States or in our repair workshop in Clarksburg, NJ.
